Chapter 6: Mixer Function
Level/pan settings
LEVEL
You can adjust the input level of each channel (LEVEL) and the master output level (MASTER).
Range: 0–127
■ When TRACK MIX channels are selected: ■ When THRU MIX channels are selected:
✐ TIPS :
• Since the channel faders on the top panel always allows you to adjust the TRACK MIX channel level,
you can use the faders to set the track level even when the THRU MIX channels are selected.
• You can use the [MASTER] fader on the top panel to adjust the master output level.
When this screen is displayed, the [F5] key and the [F6] key function as follows:
• EFFECT [F5] key ... Recalls the screen used to set the internal effects. (Needs optional EB2M)
• SCENE [F6] key...... Recalls the SCENE MEMORY window used to store and recall a scene memory.
➸ NOTE : If you use the [JOG] dial to change the level of the TRACK MIX channels, the fader position
and the actual value of the level will not match. This condition is indicated by a dot (•) that appears above
the graphic field of the screen.
PAN
You can adjust the stereo image for the channels (PAN).
Range: R63–0–L63
■ When TRACK MIX channels are selected: ■ When THRU MIX channels are selected:
✐ TIP : Since the [PAN] controls on the top panel always allows you to adjust the TRACK MIX channels’
PAN setting, you can use the [PAN] controls to set the track pan setting even when the THRU MIX channels
are selected.
When this screen is displayed, the [F5] key and the [F6] key function as follows:
• EFFECT [F5] key ... Recalls the screen used to set the internal effects. (Needs optional EB2M)
• SCENE [F6] key...... Recalls the SCENE MEMORY window used to store and recall a scene memory.
➸ NOTE : If you use the [JOG] dial to change the TRACK MIX channels’ pan setting, a dot (•) appears
above the graphic field, indicating that the position of the [PAN] control on the top panel and the actual
value do not match.
