140
Chapter 13: Using the effects
AUTOWAH (I)
This effect adds a swelling wah.
1
3
B
Parameter Setting range Function
1 Rate 0.1 – 10.0Hz Sets the speed (rate) of swelling (LFO) of the wah effect.
2 Depth 0 – 127 Sets the depth of the effect.
3 Reso 0 – 127 Sets the amount of resonance.
TOUCH WAH (I)
This effect adds a wah effect to signals at a certain level or higher.
1
3
B
Parameter Setting range Function
1 Thresh –60dB – 0dB Sets the signal level at which the wah effect becomes effective.
2 Depth 0 – 127 Sets the depth of the effect.
3 Reso 0 – 127 Sets the amount of resonance.
CHORUS>DELAY (G)
This effect consists of a chorus effect and a delay effect connected in series.
4
1
3
B
5
6
Parameter Setting range Function
1 Rate 0.1Hz – 10.0Hz Sets the speed of LFO for the chorus effect.
2 Depth 0 – 127 Sets the depth of LFO for the chorus effect.
3 Fdback 0 – 127 Sets the amount of the chorus effect that is fed back.
4 Delay 1ms – 1500ms Sets the delay time of the delay effect.
5 Fdback 0 – 127 Sets the amount of the delay effect that is fed back.
6 Bounce ON/OFF Pans the delay sound left and right when turned on.
