37
Chapter 2: Recording on the DPS12
3. Use the [CHANNEL SELECT] keys on the top panel to select the channel for which you wish to set the
parameters.
In Mixer mode, the [CHANNEL SELECT] keys are used to select the desired channel. When the TRACK MIX
channels are selected, use the [CHANNEL SELECT] keys 1–12 to select TRACK MIX channels 1–12. The
cursor moves to a graphic field for the selected channel.
✐
TIP :
You may also move the cursor to a graphic field for any channel, using the
[CURSOR]
key.
4. Select the
SELECT
[F3] key and the
SELECT
[F4] key to select a mix parameter.
The following mix parameters can be selected when the DPS12 is set to default.
• EQ HIGH FREQ (base frequency of high range)
• EQ HIGH LEVEL (level of high range)
• EQ LOW FREQ (base frequency of low range)
• EQ LOW LEVEL (level of low range)
• EQ ON/OFF (equalizer on/off)
• AUX SEND-A (AUX send A level)
• AUX-A PRE/POST (AUX send A pre/post switch)
• AUX SEND-B (AUX send B level)
• AUX-B PRE/POST (AUX send B pre/post switch)
• PAN (panning)
• LEVEL (level)
• CHANNEL (channel on/off)
• SETUP (selecting EQ/AUX type)
• MIDI CONTROL (Setting used to control the mixer section via MIDI)
Example: The EQ HIGH FREQ parameter for TRACK MIX channel 2 is selected.
✐
TIP :
you may also use the
[CURSOR]
key to move the cursor to the
Select:
field, then rotate the
[JOG]
dial to select a different parameter.
5. Rotate the [JOG] dial to change the parameter value.
The selected channel parameter changes its value.
Example: The EQ HIGH FREQ parameter for TRACK MIX channel 2 is changed to
12.5K
.
