ALI-DVR1004E Series 960H DVR User Manual
APPENDIXC HDD Installation
The following procedures illustrate hard disk drive (HDD) installation in a ALI-DVR1004E series DVR without an HDD. If you
purchased your DVR without a HDD, or you want to replace the HDD installed in your DVR, use this procedure as a guideline.
C.1 DVR compatible HDDs
For the best performance of your system, install only a high-reliability security grade HDD. Security grade HDDs are designed to
stream video eciently.
C.2 HDD Installation
The the will accommodate only one internal HDD. The HDD attaches to the chassis with four screws up through the underside of the
chassis. Cables and screws needed to install the HDD are provided.
CAUTION

Follow recommended electrostatic discharge (ESD) guidelines while performing this procedure. Install the HDD in a static-free
environment, wearing a certied ESD wrist strap. If a static free environment and ESD wrist strap is not available, touch the bare
metal of the DVR chassis frequently when installing the drive to dissipate the static charge naturally generated on your skin and
clothing and avoid touching electronic components.
1. Power o the DVR, if necessary, then disconnect the power adapter and all other cables from the back of the DVR.
2. Remove the top cover from the DVR by:
a. Setting the HDD on a clean, at surface, top side down.
APPENDIX C: HDD INSTALLATION
