Chapter 5 Configure the ControlNet Network
Use this table to determine the compatible NUTs for your system.
Table 15 - Compatible NUT Values for Multiple ControlNet Networks
If the smallest NUT of a
network is (ms)
Then the largest NUT of any other network must be less
than or equal to (ms)
215
317
419
521
623
725
827
929
10 31
11 33
12 35
13 37
14 39
15 41
16 43
17 46
18 48
19 50
20 52
21 55
22 57
23 59
24 62
25 64
26 66
27 68
28 71
29 73
30 75
31 78
32 80
33 82
34 84
35 87
36 89
37...90 90
