124 Rockwell Automation Publication 1756-UM535D-EN-P - November 2012
Chapter 6 Configure the Redundancy Modules
Interpret an Event’s Extended Information
The information listed in this table can be provided (depending on the type of
event) after you have accessed the Extended Information Definition dialog box.
Export Event Log Data
After you have viewed extended information about an event, you could need to
export event data. You can export data with either of these features:
• Export Selection
• Export All - Available with enhanced redundancy system, Revision 19.052
or later
Export Selection
Use this feature to export event log data for a single or multiple event that occurs
on a primary or secondary redundancy module.
Complete these steps to export event data for a single event.
1. Launch RSLinx Classic communication software and browse to the
redundancy modules.
2. Right-click the primary redundancy module and choose
Module Configuration.
Information Type Description
Event Information The enhanced redundancy system assigns this event information:
• Event number
• Date and time the event occurred
• Event classification
Submitter Information This information reflects information specific to the module that reported the
event. Information provided in this section includes the:
• Name of the module that originated the event
• Slot number of the module that originated the event
• Serial number of the module that originated the event
Event Details This section provides these additional details about the event:
• Description of the event
• Examine the Extended Data Definition, which provides an explanation of the
event and bytes, for errors
• Extended Data Bytes (in Hexadecimal) that provides further details the event
If the redundancy modules are not available in RSLinx Classic software after
a fault, you must apply the recovery method indicated by the module
before attempting to export the Event Log data.
