126 Rockwell Automation Publication 1441-UM001B-EN-P - September 2012
Chapter 4 Loading and Unloading
If the Emonitor software cannot match the collection specification, it creates a
new collection specification using a code. The new collection specification name
has the form XXXXLMSWNNEp, where:
The parameters of the fields in the collection specification name are explained in
the Emonitor software online help.
Automatically Print Reports after Unloading
You can select reports to automatically send to a printer after unloading data from
the Dynamix. The reports contain information on the list of measurements
unloaded.
See the Emonitor software online help for more information on printing reports
and plots.
Follow these steps to automatically print reports after unloading.
1. From the Tools menu, choose Load/Unload.
The Load/Unload dialog box appears.
2. Make sure the Dynamix 2500 data collector appears in the Set up collector
button. If not, see Use the USB Connection on page 107
.
3. Click Unload Options.
XXXX maximum frequency
L number of lines
M transducer type
S signal detection
W window type
NN number of averages
E average type
p phase measurement flag
