48 Rockwell Automation Publication 1441-UM001B-EN-P - September 2012
Chapter 2 Configuring the Dynamic 2500 Data Collector
Dynamix 2500 Data
Collector Setup Screen
The Setup dialog box lets you define global options for the Dynamix 2500 data
collector. You select Setup Utility on the Main Menu to access the Setup dialog
box.
The data collector automatically displays the Setup screen when you do the
following:
• First apply power
• Perform a hardware reset.
Follow these steps to edit an option.
1. Use the up or down arrow keys to select the option.
2. Press the Right arrow key to open a list of choices.
This is an example of the timeout options.
3. Use the left arrow to make the choice.
To select an option, press the
Up or Down arrow key.
