202 Rockwell Automation Publication 1441-UM001B-EN-P - September 2012
Chapter 6 Multi-channel Measurements
Collect a Tri-axial Measurement
The Tri-axial functionality offers advanced data collection in Route and Offroute
with three channels of data collected simultaneously on X, Y and Z. Tri-axial
measurement points can be setup by using the Emonitor software then
downloaded to the instrument.
1. Once the Dynamix 2500 data collector collects the measurement, press
Enter to accept the measurement.
2. When you are finished viewing the data, press Enter to proceed to the next
point.
Overall value
Percentage
change
Cursor
