Rockwell Automation Publication 1441-UM001B-EN-P - September 2012 177
Multi-channel Measurements Chapter 6
6. Select the parameter with the arrow keys, or type in a value.
7. Press the Left arrow to save your choice.
Use the descriptions in Offroute Orbit Parameters on page 177
to help you
configure the options in the Offroute dialog box.
When you are finished setting up the parameters, you can collect the
Offroute measurement.
See Collect Orbit Measurements on page 178
for more information.
The Units, Transducer, Filter, and Sensitivity apply to
both channels. The two input channels are X and Y.
Table 1 - Offroute Orbit Parameters
Parameter Description Values/Comments
Units Sets the measurement units for the
transducer.
Disp (mil)
Disp (µm)
Transducer The transducer used to collect this
measurement.
Prox Probe
Accel
Sensitivity The sensitivity of the transducer.
The sensitivity value is included with the
transducer’s documentation or it may be
imprinted on the side of the transducer.
200 mV/EU (default)
Trigger Determines whether the trigger is on or off.
When Trigger is set to Off the rpm value must
be entered during data collection.
On
Off
Ext Trig Slope The input signal slope to be used for externally
triggering the measurement
+ve
Defines the trigger event to occur on a rising
edge.
-ve
Defines the trigger event to occur on a falling
edge.
+ve
-ve
Level The amplitude level for externally triggering
the measurement.
The level is a percentage of the trigger full
scale range.
2.0 (default)
