208 Rockwell Automation Publication 1441-UM001B-EN-P - September 2012
Chapter 7 Installing Optional Extension Modules
The Extension Manager screen appears.
3. Select the extension module you want to uninstall and press F3 (Select).
F3 (Select) toggles the selection on and off.
A checkmark appears next to that extension module.
4. Press F1 (Uninstall).
A confirmation message appears.
5. Make sure your installation card is inserted into the unit.
You must have the correct extension module card inserted to remove that
option. If the wrong card or no card is inserted then a message displays
telling you to insert the correct card.
This screen lists the
extension modules
currently installed and the
on the unit.
