Allen-Bradley MicroLogix 1100 User Manual

Publication 1763-UM001E-EN-P - June 2015
Specifications 161
Standard DC Input Filter Settings (Inputs 4 and higher)
Nominal Filter Setting (ms) ON Delay (ms) OFF Delay (ms) Maximum Frequency (Hz)
50% Duty Cycle
Minimum Maximum Minimum Maximum
0.500 0.090 0.500 0.020 0.500 1.0 kHz
1.000 0.500 1.000 0.400 1.000 0.5 kHz
2.000 1.100 2.000 1.300 2.000 250 Hz
4.000 2.800 4.000 2.700 4.000 125 Hz
8.000
(1)
5.800 8.000 5.300 8.000 63 Hz
16.000 11.000 16.000 10.000 16.000 31 Hz
(1) This is the default setting.
Working Voltage (1763-L16AWA)
Description 1763-L16AWA
Power supply input to backplane isolation Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s
265V AC Working Voltage (IEC Class 2 reinforced insulation)
Input group to backplane isolation Verified by one of the following dielectric tests:1517V AC for 1 s or 2145V DC for 1 s
132V AC Working Voltage (IEC Class 2 reinforced insulation)
Input group to input group isolation Verified by one of the following dielectric tests:1517V AC for 1 s or 2145V DC for 1 s
132V AC Working Voltage (basic insulation)
Output group to backplane isolation Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s
265V AC Working Voltage (IEC Class 2 reinforced insulation)
Output group to output group isolation Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1s
265V AC Working Voltage (basic insulation) 150V AC Working Voltage (IEC Class 2 reinforced
insulation).
Working Voltage (1763-L16BWA)
Description 1763-L16BWA
Power supply input to backplane isolation Verified by one of the following dielectric tests:1836V AC for 1 s or 2596V DC for 1 s
265V
AC Working Voltage (IEC Class 2 reinforced insulation)
Input group to backplane isolation and
input group to input group isolation
Verified by one of the following dielectric tests: 1200V AC for 1 s or 1697V DC for 1 s
75V DC Working Voltage (IEC Class 2 reinforced insulation)
Output group to backplane isolation Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s
265V
AC Working Voltage (IEC Class 2 reinforced insulation).
Output group to output group isolation Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s
265V
AC Working Voltage (basic insulation) 150V Working Voltage (IEC Class 2 reinforced
insulation)

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
