Allen-Bradley MicroLogix 1100 User Manual

Publication 1763-UM001E-EN-P - June 2015
Wiring Your Controller 45
Recommended Surge Suppressors
Use the Allen-Bradley surge suppressors shown in the following table for use
with relays, contactors, and starters.
Recommended Surge Suppressors
Device Coil Voltage Suppressor Catalog
Number
Bulletin 509 Motor Starter
Bulletin 509 Motor Starter
120V AC
240V AC
599-K04
(1)
599-KA04
(1)
(1)
Varistor – Not recommended for use on relay outputs.
Bulletin 100 Contactor
Bulletin 100 Contactor
120V AC
240V AC
199-FSMA1
(2)
199-FSMA2
(2)
(2)
RC Type – Do not use with Triac outputs.
Bulletin 709 Motor Starter 120V AC
1401-N10
(2)
Bulletin 700 Type R, RM Relays AC coil None Required
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
12V DC
12V DC
199-FSMA9
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
24V DC
24V DC
199-FSMA9
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
48V DC
48V DC
199-FSMA9
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
115-125V DC
115-125V DC
199-FSMA10
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
230-250V DC
230-250V DC
199-FSMA11
Bulletin 700 Type N, P, or PK Relay 150V max, AC or DC
700-N24
(2)
Miscellaneous electromagnetic
devices limited to 35 sealed VA
150V max, AC or DC
700-N24
(2)

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
