164 Specifications
EFT/B immunity For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-4: 2 kV, 5 kHz on signal ports
For all other modules
IEC1000-4-4: 2 kV, 5 kHz
Surge transient immunity For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-5: 2 kV common mode, 1 kV differential mode
For all other modules
IEC1000-4-5: 2 kV common mode, 1 kV differential mode
Conducted RF immunity For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-6: 10V, 0.15…80 MHz
(2)
For all other modules:
IEC1000-4-6: 10V, 0.15…80 MHz
(2)
(1) Refer to the module’s Installation Instruction for exact operating temperature range.
(2) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is 30…1000 MHz.
General Specifications
Specification Value
Input Specifications
Specification 1762-IA8 1762-IQ8 1762-IQ16 1762-IQ32T 1762-IQ8OW6
Shipping weight,
approx. (with carton)
209 g (0.46 lbs.) 200 g (0.44 lbs.) 230 g (0.51 lbs.) 200g (0.44 lbs.) 280g (0.62 lbs.)
Voltage category 100/120V AC 24V DC
(sink/source)
(1)
24V DC
(sink/source)
(1)
24V DC
(sink/source)
(1)
24V DC
(sink/source)
(1)
Operating voltage
range
79V AC…132V AC
at 47 Hz…63 Hz
10…30V DC at
30 °C (86 °F)
10…26.4V DC at
55 °C (131 °F)
10…30V DC
10…26.4V DC
(3)(2)
10…30V DC
(24 points) at 30 °C
(86 °F)
10…26.4V DC
(23 points) at 60 °C
(140 °F)
10…30V DC at
30 °C (86 °F)
10…26.4V DC at
65 °C (149 °F)
Number of inputs 8 8 16 32 8
Bus current draw, max. 50 mA at 5V DC
(0.25W)
50 mA at 5V DC
(0.25W)
70 mA at 5V DC
(0.35W)
(3)
170 mA at 5V DC
0 mA at 24V DC
110 mA at 5V DC
80 mA at 24V DC
Heat dissipation, max. 2.0 W 3.7 W 4.3 W at 26.4V
5.4 W at 30V
(3)
5.4 W at 26.4V DC
6.8 W at 30V DC
5.0 W at 30V DC
4.4 W at 26.4V DC
(The Watts per
point, plus the
minimum W, with
all points
energized.)
Signal delay, max. On delay: 20.0 ms
Off delay: 20.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
Off-state voltage, max. 20V AC 5V DC 5V DC 5V DC 5V DC
Off-state current, max. 2.5 mA 1.5 mA 1.5 mA 1.0 mA 1.5 mA

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
