Allen-Bradley MicroLogix 1100 User Manual

Publication 1763-UM001E-EN-P - June 2015
176 Specifications
1762-IT4 Repeatability at 25 °C (77 °F)
(1) (2)
(1) Repeatability is the ability of the input module to register the same reading in successive measurements for the
same input signal.
(2) Repeatability at any other temperature in the 0…60 °C (32…140 °F) range is the same as long as the
temperature is stable.
Input Type Repeatability for
10 Hz Filter
Thermocouple J ±0.1 °C [±0.18 °F]
Thermocouple N (-110…1300 °C [-166…2372 °F]) ±0.1 °C [±0.18 °F]
Thermocouple N (-210…-110 °C [-346…-166 °F]) ±0.25 °C [±0.45 °F]
Thermocouple T (-170…400 °C [-274…752 °F]) ±0 .1 °C [±0.18 °F]
Thermocouple T (-270…-170 °C [-454…-274 °F]) ±1.5 °C [±2.7 °F]
Thermocouple K (-270…1370 °C [-454…2498 °F]) ±0.1 °C [±0.18 °F]
Thermocouple K (-270…-170 °C [-454…-274 °F]) ±2.0 °C [±3.6 °F]
Thermocouple E (-220…1000 °C [-364…1832 °F]) ±0.1 °C [±0.18 °F]
Thermocouple E (-270…-220 °C [-454…-364 °F]) ±1.0 °C [±1.8 °F]
Thermocouples S and R ±0.4 °C [±0.72 °F]
Thermocouple C ±0.2 °C [±0.36 °F]
Thermocouple B ±0.7 °C [±1.26 °F]
±50 mV ±6 μV
±100 mV ±6 μV
1762-IT4 Accuracy
Input Type
(1)
With Autocalibration Enabled Without Autocalibration
Accuracy
(2) (3)
for 10 Hz, 50 Hz and
60 Hz Filters (max.)
Maximum Temperature
Drift
(2) (4)
at 25 °C [77 °F]
Ambient
at 0…60 °C
[32…140 °F]
Ambient
at 0…60 °C [32…140 °F]
Ambient
Thermocouple J (-210…1200 °C [-346…2192 °F]) ±0.6 °C [±1.1 °F] ±0.9 °C [±1.7 °F] ±0.0218 °C/ °C [±0.0218 °F/ °F]
Thermocouple N (-200…1300 °C [-328…2372 °F]) ±1 °C [±1.8 °F] ±1.5 °C [±2.7 °F] ±0.0367 °C/ °C [±0.0367 °F/ °F]
Thermocouple N (-210…-200 °C [-346…-328 °F]) ±1.2 °C [±2.2 °F] ±1.8 °C [±3.3 °F] ±0.0424 °C/ °C [±0.0424 °F/ °F]
Thermocouple T (-230…400 °C [-382…752 °F]) ±1 °C [±1.8 °F] ±1.5 °C [±2.7 °F] ±0.0349 °C/ °C [±0.0349 °F/ °F]
Thermocouple T (-270…-230 °C [-454…-382 °F]) ±5.4 °C [±9.8 °F] ±7.0 °C [±12.6 °F] ±0.3500 °C/ °C [±0.3500 °F/ °F]
Thermocouple K (-230…1370 °C [-382…2498 °F]) ±1 °C [±1.8 °F] ±1.5 °C [±2.7 °F] ±0.4995 °C/ °C [±0.4995 °F/ °F]
Thermocouple K (-270…-225 °C [-454…-373 °F]) ±7.5 °C [±13.5 °F] ±10 °C [± 18 °F] ±0.0378 °C/ °C [±0.0378 °F/ °F]
Thermocouple E (-210…1000 °C [-346…1832 °F]) ±0.5 °C [±0.9 °F] ±0.8 °C [±1.5 °F] ±0.0199 °C/ °C [±0.0199 °F/ °F]

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
