A–15Setting Up the DH-485 Network

Publication

1747-6.2

The figure below shows the external wiring connections and

specifications of the link coupler.

TERMINATION

COMMON

SHIELD

CHASSIS GROUND

SLC 500

DH–485 LINK COUPLER

CAT SER

EXTERNAL POWER REQUIREMENTS

24 VDC +/– 25% A

T 190 mA

N.E.C. CLASS 2

24VDC

CHS

GND

NEUT

MADE IN U.S.A.

CAUTION –

EXTERNAL POWER, IF USED, MUST BE 24VDC

PERMANENT DAMAGE TO CIRCUITRY WILL RESULT

IF MISWIRED WITH THE WRONG POWER SOURCE.

FAC 1P

LISTED IND. CONT

. EQ.

FOR HAZ. LOC. A196

OPERATING

TEMPERATURE

CODE T3C

CLASS

GROUPS A, B, C AND D, DIV

. 2

CHS

GND

NEUT

VDC
