4–3
Mounting Your SLC 500 Control System
Publication
1747-6.2
10-Slot Modular Chassis
145
(5.71)
Left Side View
1.
0
(0.04)
158
(6.22)
140
(5.51)
140
(5.51)
140
(5.51)
455
(17.91)
435
(17.13)
55
(2.17)
1
1 Dia.
(0.433)
5.5 Dia.
(0.217)
171
(6.73)
14
(0.55)
Front View
481
(18.94)
123
millimeters
(inches)
5.5 Dia
(0.217)
140
(5.51)
Dimensions for power supply catalog number 1746-P1
Dimensions for power supply catalog number 1746-P2 & 1746-P3
Dimensions for power supply catalog number 1746-P4
