Allen-Bradley SLC 500 - Chapter 11 Replacement Parts; Replacement Terminal Blocks

1 1–3Replacement Parts
Publication 1747-6.2
Description Catalog Number
Italian Memory Pak Firmware Releases 1.10 1747-R20I
English Memory Pak Firmware Releases 2.00 and Later 1747-R21
French Memory Pak Firmware Releases 2.00 and Later 1747-R21F
This table provides a list of replacement terminal blocks and their
catalog numbers.
escription
atalo umber
D
escription
C
atalo
g N
umber
Replacement Terminal Block (Red) — Used with AC I/O modules, Catalog Numbers 1746-IA16, -OA16, -IM16,
-OAP12
1746-RT25R
Replacement Terminal Block (Blue) — Used with DC I/O modules, Catalog Numbers 1746-IB16, -IC16, -IH16, -IV16,
-OBP8, -OB16, -OBP16, -OVP16 -OV16, -IN16, -IG16, -OG16
1746-RT25B
Replacement Terminal Block (Orange) — Used with relay output modules, Catalog Numbers 1746-OW16, -OX8 1746-RT25C
Replacement Terminal Block (Green) — Used with Specialty I/O modules, Catalog Numbers 1746-HSCE, -IO12,
-NR4, -NI8
1746-RT25G
Replacement Terminal Block — 2 position terminal block used with analog outputs, Catalog Numbers 1746-NO4I,
-NO4V
1746-RT26
Replacement Terminal Block — 8 position terminal block used with analog outputs, Catalog Numbers 1746-NO4I,
-NO4V
1746-RT27
Replacement Terminal Block — Used with analog input modules, Catalog Numbers 1746-NI4, -NIO4I, -NIO4V,
-FIO4I, -FIO4V
1746-RT28
Replacement Terminal Block — Used with RIO Communication Modules, Catalog Numbers 1747-SN, -DSN, -DCM 1746-RT29
Replacement Terminal Block — Used with DH-485 Link Coupler, Catalog Number 1747-AIC 1746-RT30
Replacement Terminal Block — Used with SLC 500 Remote I/O Adapter Module, Catalog Number 1747-ASB 1746-RT31
Replacement Terminal Block — Used with Thermocouple/mV Module, Catalog Number 1746-NT4 1746-RT32
Replacement Terminal Block — 3-position DH+ connector; used with SLC 5/04 Processors, Catalog Numbers
1746-L541, 1746-L542, 1747-L542P, 1747-L543
1746-RT33
Replacement Terminal
Blocks
