Allen-Bradley SLC 500

4–2 Mounting Your SLC 500 Control System
Publication 1747-6.2
7-Slot Modular Chassis
145
(5.71)
Front View
171
(6.73)
Left Side View
1.0
(0.04)
(5.51)
140
340
(13.39)
320
(12.60)
175
(6.89)
158
(6.22)
(6.73)
171
1 1 Dia.
(0.433)
5
.
5 D
ia.
(0.217)
45
(1.77)
14
(0.55)
366
(14.41)
123
millimeters
(inches)
5.5 Dia
(0.217)
140
(5.51)
