Appendix
C
Publication
1747-6.2
Setting Up the DH+ Network
This appendix provides an overview of the Data Highway Plus
(DH+) communication protocol and explains how the SLC 5/04
processors support it. This appendix also provides information on
the following:
• DH+ communication protocol overview
• SLC 5/04 processor and DH+ communication
• wiring connectors for DH+ communication for SLC 5/04
• typical DH+ network configuration
Data Highway Plus implements peer-to-peer communication with a
token-passing scheme to rotate link mastership among a maximum of
64 nodes. Since this method does not require polling, it helps
provide time-efficient reliable data transport. The DH+ features:
• remote programming of PLC-2, PLC-3, PLC-5 and SLC 500
processors on your network
• direct connections to PLC-5 processors and industrial
programming terminals
• easy re-configuration and expansion if you want to add more
nodes later
• a communication rate of 57.6K baud, 115.2K baud, or 230.4K
baud
Important: A programming device, such as an IBM compatible PC,
using a 1784-KT Communication Interface module
does not operate faster than 57.6K baud. The
1784-KTXD can operate at all three communication
rates.
The following table summaries the type of termination resistor
needed to stop communicating at the specified baud rate with the
maximum cable length.
Termination Link
Resistor Value
Ω
Communication Rate
(Kbaud)
Maximum Cable
Length m (ft)
150 57.6 3,048 (10,000)
150 115 1,542 (5,000)
82 230.4 762 (2,500)
D
H
ghw
Communication Protocol
