Allen-Bradley SLC 500

4–5 Mounting Your SLC 500 Control System
Publication 1747-6.2
Link Coupler (AIC)
Front View
159
(6.24)
137
(5.41)
14
(0.55)
38
(1.50)
R 2.74
(0.11)
5.5 Dia.
(0.216)
5.5
(0.22)
146
(5.75)
4.3
(0.17)
R
Right Side View
172
(6.75)
7.1
(0.28)
millimeters
(inches)
Data Table Access Module (DTAM, DTAM Plus, and DTAM Micro)
C
Right Side View
D
B
A
Front View
Comm
DTAM
DTAM Plus
DT
AM Micro
A B C D
193
(7.6)
165.1
(6.5)
45.7
(1.8)
215.9
(8.5)
99.1
(3.9)
175.3
(6.9)
45.7
(1.8)
137.2
(5.4)
127
(5.0)
140
(5.5)
69
(2.76)
152
(6.0)
millimeters
(inches)
