F–4 Calculating Heat Dissipation for the SLC 500 Control System
Publication 1747-6.2
Hardware Component Catalog Numbers Watts per Point Minimum Watts Total Watts
1746-BAS not applicable 3.75 3.8
1746-HSCE not applicable 1.6 1.6
Spe
cialt
y M
o
d
ul
es
1746-NR4
not applicable 1.5 1.5
Spe
cialt
y M
o
d
ul
es
1746-NT4
not applicable 0.8 0.8
1746sc-NT8
➀
0.00 3.0 3.0
1747-SN not applicable 4.5 4.5
R ot oul
1747-ASB not applicable 1.875 1.875
R
em
ot
e I/O M
o
d
ul
es
1747-DSN
not applicable 4.5 4.5
1747-DCM not applicable 1.8 1.8
1747-KE not applicable 3.75 3.8
Communication Modules
1747-AIC
not applicable 2.0 2.0
o unication o ul
1747-PIC not applicable 2.0 2.0
Data Table Access Module 1747-DTAM not applicable 2.5 2.5
Hand-Held Terminal 1747-PT1 Series A & B not applicable 2.5 2.5
➀
Sold and supported by Spectrum Controls, Inc., Bellevue, W A. For additional information, contact Spectrum at (206) 746-9481.
