Allen-Bradley SLC 500

2–25 Selecting Your Hardware Components
Publication 1747-6.2
!
ATTENTION: Damage could occur to SLC 500 triac
outputs if you use suppressors having RC networks.
Allen-Bradley AC surge suppressors not recommended
for use with triacs include Catalog Numbers
199-FSMA1, 199-FSMA2, 1401-N10, and 700-N24.
Allen-Bradley surge suppressors recommended for use with
Allen-Bradley relays, contactors, and starters are shown in the table
below.
Device Coil Voltage
Suppressor Catalog
Number
Bulletin 509 Motor Starter
Bulletin 509 Motor Starter
120V ac
240V ac
599-K04
➀
599-KA04
➀
Bulletin 100 Contactor
Bulletin 100 Contactor
120V ac
240V ac
199-FSMA1
➁
199-F5MA2
➁
Bulletin 709 Motor Starter 120V ac
1401-N10
➁
Bulletin 700 Type R, RM
Relays
AC coil None Required
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
12V dc
12V dc
700-N22
700-N28
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
24V dc
24V dc
700-N10
700-N13
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
48V dc
48V dc
700-N16
700-N17
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
115-125V dc
115-125V dc
700-N11
700-N14
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
230-250V dc
230-250V dc
700-N12
700-N15
Bulletin 700 Type N, P, or PK
Relay
150V max, AC or DC
700-N24
➁
Miscellaneous electromagnetic
devices limited to 35 sealed
VA
150V max, AC or DC
700-N24
➁
➀
Series C or later of these catalog numbers do not contain capacitors. They are recommended for
use with SLC 500 triac outputs.
➁
Not recommended for use with triac outputs.
