5–13

Identifying the Components of Your Processor

Publication

1747-6.2

The figure below shows some of the hardware components of the

SLC 5/05 processors (1747-L551, 1747-L552, and 1747-L553).

Left Side View Front View

Location of Serial and

Catalog Numbers

Memory Module

Keyswitch

Battery

(provides

back-up

power for the

CMOS RAM)

SLC

5/05 CPU

RUN PROG

FORCE

RS232

BATT

ENET

FLT

RUN

REM

Channel 1

Ethernet

(10Base-T)

Channel 0

RS232

(DH485,

DF1, or

ASCII)

Operating System

Memory Module

Download Protection

Jumper

Hardware

Address

xx:xx:xx

Write-on

Area for

Address

ADDRESS

_______ . _______ . _______ . _______
