218 Explicit Messages
Read
Monitor
Status of
Test Output
Total on Time
or Contact
Operation
Counter
Read Reads the monitor status
of the total on time or
contact operation
counter for the test
output (1…4) specified
by the Instance ID.
0E hex 35B
hex
01…04
hex
85 hex
—
1 byte
00 hex: in range
01 hex: out of range
(over monitor value)
Read Test
Output
Safety Flag
Read Reads the normal flag
status for the test output
(1…4) specified by the
Instance ID.
0E hex 35B
hex
01…04
hex
68 hex
—
1 byte
00 hex: normal
01 hex: error
Read Test
Output Error
Information
Cause
Read Reads the cause for the
normal flag of the test
output (1…4) specified
by the Instance ID being
off (error).
0E hex 35B
hex
01…04
hex
76 hex
—
1 byte
00 hex: no error
01 hex: invalid
configuration
02 hex: overcurrent
detection
05 hex: high
constant error
06 hex: undercurrent
detection
Read OR of
Test Output
Safety Flags
Read Reads the logical OR of
the normal flag for all
test outputs (1…4).
0E hex 35C
hex
01 hex 69 hex
—
1 byte
00 hex: all normal
01 hex: error
Read OR of
Monitor
Status of
Test Output
Total On
Times or
Contact
Operation
Counters
Read Reads the logical OR of
the monitor status of the
total on time or contact
operation counter for all
test outputs (1…4).
0E hex 35C
hex
01 hex 72 hex
—
1 byte
00 hex: all in range
01 hex: test output
out of range (over
monitor value)
Monitoring Test Output Terminals
Explicit
Message
Service Function
Command
Response
Service
Code
Class
ID
Instance
ID
Attribute
ID
Data Size
