208 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Appendix A Parameter Information
111 Cur Imbal F Dly Secs 0.1/99 3.0 The time period that the current imbalance exceeds the Cur
Imbal F Lvl to signal a fault. The Cur Imbal bit in the Motor Fault
En parameter must be set to signal a fault.
R/W
112 Cur Imbal A Lvl % 1/25 15 If the line-to-line current imbalance condition exceeds the Cur
Imbal A Lvl for the time period set in Cur Imbal A Dly, an alarm
will be signalled. The Cur Imbal bit must be set in the Motor
Alarm En parameter to signal a Alarm.
R/W
113 Cur Imbal A Dly Secs 0.1/99 3.0 The time period that the current imbalance exceeds the Cur
Imbal A Lvl to signal an alarm. The Cur Imbal bit in the Motor
Alarm En parameter must be set to signal an alarm.
R/W
114 Jam F Lvl %FLC 0/1000 1000 If the peak phase current exceeds the Jam F Lvl for the time
period set in Jam F Dly, a fault will be signaled. The Jam bit
must be set in the Motor Fault En parameter to signal a fault.
R/W
115 Jam F Dly Secs 0.1/99 0.1 The time period that the peak phase current exceeds the Jam F
Lvl to signal a fault. The Jam bit in the Motor fault En parameter
must be set to signal a fault.
R/W
116 Jam A Lvl %FLC 0/1000 1000 If the peak phase current exceeds the Jam A Lvl for the time
period set in Jam A Dly, an alarm will be signaled. The Jam bit
must be set in the Motor Alarm En parameter to signal a alarm.
R/W
117 Jam A Dly Secs 0.1/99 0.1 The time period that the peak phase current exceeds the Jam A
level to signal an alarm. The Jam bit in the Motor Alarm En
parameter must be set to signal a alarm.
R/W
118 THD V F Lvl % 0/1000 1000 If the average total harmonic distortion (THD) on the line
voltage exceeds the THD V F Lvl for the time period set in THD V
F Dly, a fault will be signaled. The THD V bit must be set in the
Starter Fault En parameter to signal a fault.
R/W
119 THD V F Dly Secs 0.1/99 0.1 The time period that the average THD on the line voltage
exceeds the THD V F Lvl to signal a fault. The THD V bit in the
Starter Fault En parameter must be set to signal a fault.
R/W
120 THD V A Lvl % 0/1000 1000 If the average THD on the line voltage exceeds the THD V A Lvl
for the time period set in THD V Dly, an alarm will be signaled.
The THD V bit must be set in the Starter Alarm parameter to
signal a alarm.
R/W
121 THD V A Dly Secs 0.1/99 0.1 The time period that the average THD on the line voltage
exceeds the THD V A Lvl to signal a alarm. The THD V bit in the
Starter Alarm parameter must be set to signal an alarm.
R/W
122 THD I F Lvl % 0/1000 1000 If the average THD on the phase current exceeds the THD I F Lvl
for the period set in THD I F Dly, a fault will be signalled. The
THD I bit must be set in the Motor Fault En parameter to signal a
fault.
R/W
123 THD I F Dly Secs 0.1/99 0.1 The time period that the average THD on the phase current
exceeds the THD I F Lvl to signal a fault. The THD I bit in the
Motor Fault En parameter must be set to signal a fault.
R/W
124 THD I A Lvl % 0/1000 1000 If the average THD on the phase current exceeds the THD I A Lvl
for the time period set in THD I A Dly, an alarm will be signaled.
The THD I bit must be set in the Motor Alarm En parameter to
signal an alarm.
R/W
Table 66 - SMC -50 Parameter List (Continued)
Number Name Unit Min/Max Default Enum Text Description R/W
