Allen-Bradley SMC-50 User Manual

258 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Appendix E ArcShield Plenum Installation Instructions
Figure 82 - Plenum Exhaust Label
Figure 83 - Various Plenum Components Available
18 in. wide Plenum
Fastened directly over the 0.5 m (18 inch)
wide cabinet
26 in. wide Plenum
Fastened directly over the 0.7 m (26 inch)
wide cabinet
36 in. wide Plenum
Fastened directly over the 0.9 m (36 inch)
wide cabinet
DANGER DANGER
ARC FLASH HAZARD
PRESSURE RELIEF EXIT
AREAS TO BE:
- INACCESSIBLE TO PERSONNEL
WHILE EQUIPMENT ENERGIZED.
- FREE OF OBSTRUCTIONS
(REFER TO USER MANUAL).
SEVERE INJURY OR
DEATH MAY RESULT.
HAZARD D’ARC ÉLECTRIQUE
SORTIE DE L’ÉVENT
RÉGION ÊTRE:
- INACCESSIBLE AUX PERSONNEL
PENDANT QUE L’ÉQUIPEMENT
EST SOUS TENSION.
- DÉMUNI D’OBSTRUCTIONS
(RÉFÉRER AU MANUEL)
RISQUE DE BLESSURES
CORPORELLES GRAVES
OU MÊME LA MORT.
