Appendix H Spare Parts
Table 84 - Common Parts
a
Quantity Description Part Number
1 per SCR pair
(1)
(1) Refer to Tabl e 8 1 for an explanation of the number of SCRs per controller, which is voltage dependant.
Sharing resistor 32.5 kΩ, 225W, two 2.5 kΩ taps 80025-753-01-R
1 per SCR
(1)
Current loop self-powered gate driver board (CLGD) 80190-519-01-R
1 per controller Voltage Sensing Board (VSB) 1500V 80187-708-51-R
2500V 80187-708-52-R
4800V 80187-708-54-R
7200V 80187-708-55-R
(1 per SCR) + 3
(1)
Fiber Optic Cable 2.5 m 80025-549-03-R
5.0 m 80025-549-01-R
1 per controller Test Power Supply 120V AC for North America 80187-051-51-R
Universal 80187-245-51-R
1 per controller Current loop transformer, 50VA 115/230 : 0.6V 80022-133-01
3 per controller
(2)
(2) Different lengths are used for the various configurations. The current loop total length must equal 21 ft. for proper operation.
Current loop cable assembly 5 ft. 80018-246-55
6 ft. 80018-246-51
7 ft. 80018-246-52
8 ft. 80018-246-53
9 ft. 80018-246-54
1 per controller Current loop sense CT 80022-163-01
1 per controller Ribbon cable from VSB to Interface Board 80026-146-56
3 per controller Ribbon cable from Control Module to Interface Board (6-pin) 80174-201-01
3 per controller Ribbon cable from Control Module to Interface Board (8-pin) 80174-201-02
Table 85 - Interface Board
Quantity Description Part Number
1 per controller 180 A, 1500…2400V controller PN-539324
1 per controller 180 A, 3300…4160V controller PN-539325
1 per controller 180 A, 6600…6900V controller PN-539326
1 per controller 360 A, 1500…2400V controller PN-539327
1 per controller 360 A, 3300…4160V controller PN-539328
1 per controller 360 A, 6600…6900V controller PN-539329
1 per controller 600 A, 1500…2400V controller PN-539330
1 per controller 600 A, 3300…4160V controller PN-539331
1 per controller 600 A, 6600…6900V controller PN-539332
