Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 95
Programming Chapter 4
5. With Basic highlighted, press ENTER (number 5 on the keypad).
6. Scroll to the desired parameter (for example, Line Voltage) to modify it,
then press ENTER (number 5 on the keypad).
7. With the parameter displayed, press the EDIT soft key.
8. Enter the desired value, then press the ENTER soft key to save the value.
9. Press the ESC key to return to the Basic category.
10. To modify another parameter in the Basic category, follow steps 5
though
7
. To return to a higher level category, press the BACK arrow key.
TIP Using the DEV PARAM folder screen and the File-Group selection, the
controller parameters can be selected and configured by functional
category. See the Parameter File-Group Structure
on page 109.
PROPERTIES
AUTO
Stopped
0 Amps
Allen-Bradley
ESC
Port 00 Param File-Group
F
FILE Monitoring
FILE Set Up
FILE Motor Protection
FILE Communications
FILE Utility
