Page #12 background imageLoading...
Page #12 background image
1-2 Switch Description
The AT-9724TS has 24 1000T Gigabit ports that may be used in uplinking various network devices to the Switch, including PCs, hubs and other switches to
provide a gigabit Ethernet uplink in full-duplex mode.
In addition, the AT-9724TS is equipped with 4 SFP (Small Form Factor Portable) combo ports, which are to be used with fibre-optical transceiver cabling in order
to uplink various other networking devices for a gigabit link that may span great distances.These 4 SFP ports support full-duplex transmissions, have auto-
negotiation and can be used with AT-MG8LX10 (1000LX),AT-MG8SX (1000SX) and AT-MG8ZX (1000ZX) transceivers.These four ports are referred to as
“combo” ports which means that both the SFP ports and the 1000T ports are numbered the same (21–24) and cannot be used simultaneously.Attempting to use
the ports simultaneously will cause a link down status for the 1000T ports. SFP ports will always have priority over these 1000T ports.
Also included at the rear of the Switch are two 10-gigabit stacking ports used to stack up to twelve switches in a ring topology.The AT-9724TS may be used as
the master unit of a switch stack when utilizing these ports and, in total, may provide a stacking solution of up to 288 gigabit ports.
Note: The four SFP combo ports on the Switch, numbered 21–24 cannot be used simultaneously with the corresponding 1000T ports, numbered
21–24. If both ports are in use at the same time (ex. port 21 of the SFP and port 21 of the 1000T), the SFP ports will take priority over the combo
ports and render the 1000T ports inoperable.
1-3 Features
IEEE 802.3z compliant
IEEE 802.3x Flow Control in full-duplex compliant
IEEE 802.3u compliant
IEEE 802.3ab compliant
IEEE 802.3ae compliant (for optional XFP module)
IEEE 802.1p Priority Queues
IEEE 802.3ad Link Aggregation Control Protocol support.
IEEE 802.1x Port-based and MAC-based Access Control
IEEE 802.1Q VLAN
IEEE 802.1D Spanning Tree, IEEE 802.1W Rapid Spanning Tree and IEEE 802.1s Multiple Spanning Tree support
Stacking support in Ring topology
Access Control List (ACL) support
IP Multinetting support
Protocol VLAN support
Single IP Management support
Access Authentication Control utilizing TACACS, XTACACS,TACACS+ and RADIUS protocols
Dual Image Firmware
Simple Network Time Protocol support
MA
C Notification support
System and P
ort Utilization support
System Log Support
High performance switching engine performs forwarding and filtering at full wire speed up to 128Gbps.
Full- and half-duplex for all gigabit ports. Full duplex allows the switch port to simultaneously transmit and receive data. It only works with
connections to full-duplex-ca
pable end stations and s
witches.
Connections to a hub m
ust take place at half-duplex.
Suppor
t broadcast storm filtering
Non-blocking stor
e and f
orward switching scheme capability to support rate adaptation and protocol conversion
Supports by-port Egress/Ingress rate control
Efficient self-learning and address recognition mechanism enables forwarding rate at wire speed
Support port-based enable and disable
Address table: Supports up to 8K MAC addresses per device
Supports a packet buffer of up to 3 Mbits
Supports Port-based VLAN Groups
Port Trunking with flexible load distribution and fail-over function
IGMP Snooping support
Layer 3 support including DVMRP, OSPF and RIP
11
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch

Table of Contents

Other manuals for Allied Telesis AT-9724TS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Allied Telesis AT-9724TS and is the answer not in the manual?

Allied Telesis AT-9724TS Specifications

General IconGeneral
MAC address table16000 entries
Packet buffer memory2 MB
Maximum data transfer rate88 Gbit/s
Full duplexYes
Dimensions (WxDxH)440 x 210 x 44 mm
Power requirements100-240V AC/50-60Hz
Management platformSNMP, RMON
Networking featuresIEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technologyWired
DHCP featuresDHCP client
Security algorithmsSSH
Switch typeManaged
Switch layerL3+
SFP/SFP+ slots quantity4
Basic switching RJ-45 Ethernet ports quantity24
Memory typeSDRAM / Flash
Flash memory16 MB
Internal memory256 MB
Power consumption (typical)90 W
CertificationUL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)-25 - 55 °C
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Weight3200 g
