Allied Telesis AT-9724TS User Manual

Appendix A - Technical Specifications
General
Sta
ndard
IEEE 802.3u 100TX Fast Ethernet
IEEE 802.3ab 1000T Gigabit Ethernet
IEEE 802.1 P/Q VLAN
IEEE 802.3x Full-duplex Flow Control
IEEE 802.3 Nway auto-negotiation
Protocols CSMA/CD
Data Transfer Rates: Half-duplex Full-duplex
Ethernet 10Mbps 20Mbps
Fast Ethernet 100Mbps 200Mbps
Gigabit Ethernet 1000Mbps 2000Mbps
Fibre Optic IEC 793-2: 1992
Type A1a - 50/125um multi-mode
Type A1b - 62.5/125um multi-mode
Both types use LC optical connector
Topology Ring
Network Cables UTP Cat.5 for 100Mbps
UTP Cat.3, 4, 5 for 10Mbps
EIA/TIA-568 100-ohm screened twisted-pair (STP)(100m)
Physical & Envir
onmental
AC inputs & External
R
edunda
nt Power Supply
100 – 240
V
AC, 50/60 Hz (internal universal power supply)
P
o
w
er Consumption:
90 watts maxim
um
DC fans: 2 built-in 40 x 40 x 10 mm fans; 1 built-in 60 x 60 x 18 mm fan
Oper
ating T
emper
atur
e:
0 to 40 degr
ees C
Storage Temperature: -25 to 55 degrees C
Humidity: Operating:
5% to 95% RH non-condensing
Storage: 0% to 95% RH non-condensing
Dimensions: 441 mm x 207 mm x 44 mm (1U), 19 inch rackmount width
Weight: 3.15 kg
EMC: FCC Part 15 Class A/ ICES-003 Class (Canada)
EN55022 Class A / EN55024
Safety: CSA International
190
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
