Technical Data
InstallatIon
Only in frost-free, dry and weatherproof rooms.
Ambient temperature: 0 °C – 35 °C
Electrical connection: 230 V AC, 18 VA, 0.1 A
(max. power consumption regulator
without any appliances connected)
outputs
Relay contacts: 8 A / 230 V,
Fuse: 6.3 AT (for all relay outputs)
In total consumers up to 1,450 VA can be connected to the
outputs.
Inputs
Optocoupler: 230 V
Sensor inputs: NTC sensor 2.2 kΩ / 25 °C
connectIons
Control line: 12-pole, outputs 230 V
Sensor line: 12-pole, low voltage
Plug-in terminals: 1-pole, screw terminals
Interfaces
USB: USB version 2.0 (USB 2.0)
Host, A plug (only for a USB stick!)
Ethernet: 1 x 10 Base-T / 100 Base-TX
(RJ-45, plug, bent)
protectIon class
Protection class IP 20
temperature sensor characterIstIcs
t / °C R / kΩ
-20 16,538
-15 12,838
-10 10,051
-5 7,931
a/-0 6,306
+5 5,040
+10 4,056
+15 3,283
+20 2,674
+25 2,200
+30 1,825
+35 1,510
+40 1,256
+45 1,056
+50 0,891
+55 0,751
+60 0,636
+65 0,534
sensor measurIng range
Type of
sensor
Measuring range
Autom. value
in case of
sensor defect
TVL -10 °C bis 80 °C 5 °C
TRL -10 °C bis 125 °C 5 °C
TRL-E -10 °C bis 125 °C 5 °C
THG -25 °C bis 140 °C 150 °C
TA -35 °C bis 55 °C -5 °C
TBW 0 °C bis 125 °C 75 °C
TWE -40 °C bis 70 °C -50 °C
TWA -40 °C bis 70 °C -50 °C
TB1 0 °C bis 100 °C 75 °C
RFV -5 °C bis 5 °C 0 °C
