Alpha-InnoTec Luxtronik 2.0 User Manual

78
We reserve the right to make technical changes.
83052300eUK © ait-deutschland GmbH
Parameter Factory setting Setting Start-up Value range Access
Limit return
45 °C °C *) 35 °C – 70 °C
Fitter
Hysteres HC
2,0 K K *) 0,5 – 3,0 K
Fitter
RTincr.e max
7,0 K K *) 1,0 – 7,0 K
AS
Release 2 CP
5 °C °C *) -20 °C – 20 °C
Fitter
Release 2hg
S/W & W/W: -16 °C
L/W: -2 °C
°C *) -20 °C – 20 °C
Fitter
Tp-defr. Air.
10 °C °C *) 0 °C – 20 °C
AS
TVth.disinf2
65 °C °C *) 50 °C – 70 °C
User
Hysteres. SW
2,0 K K *) 1,0 – 30,0 K
Fitter
Flow 2.CP SW
50 °C °C *) 10 °C – 70 °C
Fitter
T-outd. max
35 °C °C *) 10 °C – 45 °C
AS
T-outd. min.
-20 °C °C *) -20 °C – 10 °C
Fitter
T-HS min
S/W: -9 °C
W/W: 3,5 °C
°C *) -20 °C –10 °C
AS
Plant
T-HG max
130 °C °C *) 90 °C – 140 °C
Plant
T-def.airend
2 °C °C *) 2 °C – 10 °C
AS
Lowering to
-20 °C °C *) -20 °C – 10 °C
User
Flow max
device-dependent °C *) 35 °C – 75 °C
User
Flow max. MC1
40 °C °C *) 25 °C – 75 °C
User
min. AT ow
max.
-7 °C °C *)
-20 °C – 5 °C
Settings only possible for
reversible units
AS
Flow limit of
applic.
50 °C °C *)
35 °C – 75 °C
Settings only possible for
reversible units
AS
Hysteresis 2.CP
short
4.0 K K
Fitter
service water
max
65°C °C *) 30 °C – 65 °C
Fitter
min. ow
cooling
18°C °C 5°C - 25 °C
Fitter
El. sup. blockade
no 2hg no 2hg • with 2hg *) no 2hg • with 2hg
Fitter
Room stat.
No No • RFV *) No • RFV
User
Integratation
Return Return • Sep.tank *) Return • Sep.tank
Fitter
Mixing circ 1
No No • Charge • Discharge • Cool *)
No • Charge • Discharge •
Cool
User
Mixing circ 1
LWD reversible
No No • Charge • Discharge • Cool *)
No • Charge • Discharge •
Cool
Fitter
2hg
only Luxtronik 2.0
60 min min 20 - 120 min
Fitter
System setting during commissioning
