98 Series 90B ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL
Electrical
Surge Withstand: ANSI C37.90.1 (Oscillatory portion)
Electrical Fast Transient/Burst Immunity:
IEC 61000-4-4 (2kV DC Power, 1kV I/O)
Surge Immunity: IEC 61000-4-5 (1kV Common Mode, line-to-ground)
Dielectric Withstand:
1400 Vac or 2050 Vdc Inputs to Digital (test @ configuration port)
1400 Vac or 2050 Vdc Outputs to Digital (test @ configuration port)
1450 Vac or 2150 Vdc AC Integral Power Input to Digital (test @ configuration port)
350 Vac or 500 Vdc DC Integral Power Input to Digital (test @ configuration port)
1400 Vac or 2000 Vdc from Inputs to Outputs
1400 Vac or 2000 Vdc from Inputs to Power Input
250 V RMS from Input to Input when configured for Isolated Inputs
1400 Vac or 2000 Vdc from Outputs to Power Input
1200 Vac or 1700 Vdc from Output to Output
1400 Vac or 2000 Vdc from Inputs to Case
1200 Vac or 1700 Vdc from Outputs to Case
1400 Vac or 2000 Vdc from Integral AC Power to Case
350 Vac or 500 Vdc from Integral DC Power to Case
350 Vac or 500 Vdc from Communications Ports to DC Power
1450 Vac or 2150 Vdc from Communications Ports to AC Integral Power Input
Radiated RFI Immunity: IEC 61000-4-3 10 V/m
Conducted RFI Immunity: IEC 61000-4-6 3V
Radiated Emissions: EN 61000-6-4 (EN55011)
Conducted Emissions: EN 61000-6-4 (EN55011)
Radiated Power Frequency: IEC 61000-4-8 30 A/m Magnetic
Field
ESD Effects: IEC 61000-4-2 4kV contact 8kV air
Certifications
CE: Low Voltage Directive 73/23/EEC: EN 61010-1:2001
EMC Directive 89/336/EEC: EN 61326:1998
FM
Pending
UL Pending
Requires FM option (refer to option codes). The required door may be supplied by Ametek, a
panel shop or the customer. The door must meet the FM standard for requiring a tool to open or
remove the door to allow access to the front of the Annunciator.
