10 Series 90B ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL
I/O Module Configuration
(1087-xxx modules with auto range FCV)
J1, 2
Isolated/Common FCV
P2, 3, 4
Relay Output
Jumpers
P5, 6
NO / NC Inputs
SW1 Address
Selection
(Configured at Factory)
