Series 90B ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL
i. 7
SYSTEM CONFIGURATION AND SET-UP
The SERIES 90B Annunciator is already factory configured per the model
number. Most of the configuration of the system is made using software,
however some settings such as relay contact arrangement (Form A or Form B)
needs to be configured by the user. The default configurations are specified
below:
Item
Default
Setting
Configuration
Method
Inputs
N.O. (normally open), N.C. (normally
closed) Field Contact Inputs
N.O.
Software or
Hardware *
Field Contact Voltage
(12, 24, 48, 125VDC, 120VAC)
OR
(24-125VDC)
Factory
Configured
Per Model
Number
Hardware
Common FCV (field contact voltage)
or Isolated FCV
Hardware
Input Module Address Setting
Hardware
Operational Sequence (A, M, etc)
Software
Sequence Grouping
1 group
Software
Input Response
50 msec
Software
Critical/Non-Critical Assignment
Non-Critical
Software
Optional
Repeat Relays
Form A (normally open), Form B
Contacts (normally closed)
Form A
Hardware
Form C Contacts (SPDT)
Factory
Configured
Per Model
Number
Hardware
Energized or De-Energized Relays
De-Energized
Software
Repeat Relay Operation
Follows Input
Software
CSM Functions
Auxiliary Contact Output Type
(Form A, Form B)
Form A
Hardware
Auxiliary Contact Output Mode
(Energized or De-Energized)
De-Energized
Software
Auxiliary Contact Output Operation
(Horn, Reflash, Fault, Watchdog,
Power Monitor, Ground Fault)
Critical Horn
& Non-Critical
Horn
Software
Other system-wide functions
None
Selected
Software
Serial
Communication
Module
RS-232 , RS-485
RS-232
Software
RS-485 Termination Jumper
Out
Software
Flash Synchronization (master/slave)
Master
Hardware
* NO/NC Field Inputs can be configured via the software or hardware, but
not both. Choose one method only.
