Series 90B ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL
Input Configuration
The configuration of each alarm input is defined in this page. To simplify this procedure
a number of similar inputs may be selected at the same time and common parameters
set.
An individual input is selected by clicking on it. The input will change color when
selected. The input number will be shown in the ‘Alarms’ list. To select a number of
inputs hold down the ‘Ctrl’ key while clicking on the inputs. To de-select an input press
the ‘Ctrl’ key and click on the input again. To select a rectangular block of inputs click
on the top left hand one then drag down to the bottom right.
When one or a number of inputs has been selected the parameters for those inputs
may be set.
Alarm Numbering
The inputs are numbered left to right and top to bottom. The inputs within a
module are numbered in sequence followed by the next module. So, for
example, the top row of inputs of modules with four inputs each are:-
1, 2, 5, 6, 9, 10, ……
