4 Series 90B ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL
ANNUNCIATOR MODEL CODE DEFINITION
Item 1 Mounting Options
PM
Semi-Flush Panel Mounting
PC
Semi-Flush Panel Mounting w/rear
cover
RK
19” Rack Mounting (5 wide
systems only)
S
Surface (Wall) Mounting (1H to 5H
x 2W to 5W)
NCB
Weather-tight NEMA Front Cover
w/ ¼-20 Bolts
NCT
Weather-tight NEMA Front Cover
w/T Handle
N4
NEMA-4 Enclosure (1H to 6H x 3W
to 8W)
N4P
B
NEMA-4 Enclosure w/PB (1H to 6H
x 3W to 8W)
Item 2,3 Annunciator Size
# of Cells
H
i
g
h
(1-13)
# of Cells Wide
(2-13)
Item 4 Common Service Cell (lower
right cell)
INTB
Integral Integral Pushbuttons (ACK, SIL,
TEST, RESET)
NPB
Pushbuttons replaced w/ a Half or
Full Size Window
LPP
B
Low Profile Integral Pushbutton
attached to bezel. CSM Cell has
Half or Full Size Window
Note: For either selection above,
external pushbuttons can be
connected to the Annunciator
terminal blocks.
Item 5 Window Size
4
Quad Size, 4 inputs per cell, ea
1.5”H x 1.5”W
3
Third Size, 3 inputs per cell, ea
1.0”H x 3.0”W
2E
Half Size, 2 inputs per cell, ea
1.5”H x 3.0”W
2S
Half Size, 2 inputs per cell, ea
1.5”H x 3.0”W
2
Half Size, 2 inputs per cell, ea
1.5”H x 3.0”W
1E
Full Size, 1 input per cell, ea
3.0”Hx3.0”W
IMW
Intermixed window size
Note:
Option 1E indicates that the cell is
expandable up to 2 inputs.
Option 2E indicates that the cell is
expandable up to 4 inputs. Option 2S
indicates one input module per single input
provided.
Do not include the CSM Cell in your
quantity.
Item 6 Active Points
Total # of active points
Item 7 Window Color
W
White Window Filter
R
Red Window Filter
A
Amber Window Filter
G
Green Window Filter
Y
Yellow Window Filter
B
Blue Window Filter
IMC
Intermix color, matrix must be
included
Item 8 Operational Sequence
LN,AO,AONL,AF,AFNL,FR,AM,FRM,AS,ASFR,ASFRM,TFS,TFSFRM,TFSM,ARR,FRR,
MC, VS,VSRR
IMO
Intermixed Sequences (up to 4
available)
Item 9 Repeat Relay Option
RR
Auxiliary Repeat Relay Provided for
every Input.
(Can be field configured to follow:
alarm input status, alarm sequence
operation or Lamp Flash. Relays
can be set for normally energized
or de-energized operation and are
jumper selectable for a Form A or
Form B contact arrangement).
FRC
Auxiliary Repeat Relay Provided
for every Input with Form C
(SPDT) Contacts.
(Can only be used with Window
Size 1E or 2S).
2RR
Two Repeat Relays for every input.
(Selectable for a Form A or Form B
90B Model Number
90B- - - - - - -
______ ______ _____ _____ _____ _____ _____
Item 1 Item 2 Item 3 Item 4 Item 5 Item 6 Item 7
Mounting # of Cells # of Cells Common Window Active Window
Options High Wide Service Size Points Color
- - - - - - -
_____ _____ _____ _____ _____ _____ _____
Item 8 Item 9 Item 10 Item 11 Item 12 Item 13 Item 14
Operational Repeat Power Field Contact Window Comm. Options
Sequence Relay Input Voltage Legends Options
Example: 90B-PM-3H-6W-INTB-2-34-W-A-RR-B-X-TP-MB-TS-IB-RLY
