Ametek 90B Series User Manual

112 Series 90B ANNUNCIATOR INSTALLATION AND CONFIGURATION MANUAL
DNP V3.0
DEVICE PROFILE DOCUMENT
Timeouts while waiting for:
Data Link Confirm: Configurable.
Complete Appl. Fragment: None
Application Confirm: Configurable.
Complete Appl. Response: None
Others: Transmission Delay, configurable
Inter-character Timeout, 1 second
Need Time Delay, configurable
Frozen Counter Change Event Scan Period, Fixed at 1 second
Sends/Executes Control Operations:
WRITE Binary Outputs Never
SELECT/OPERATE Never
DIRECT OPERATE Never
DIRECT OPERATE – NO ACK Never
Count > 1 Never
Pulse On Never
Pulse Off Never
Latch On Never
Latch Off Never
Queue Never
Clear Queue Never
Reports Binary Input Change Events when no
specific variation requested:
Never
Reports time-tagged Binary Input Change Events
when no specific variation requested:
Never
Sends Unsolicited Responses:
Never
Sends Static Data in Unsolicited Responses:
Never
No other options are permitted.
Default Counter Object/Variation:
Default Object 1
Default Variation: 1
Counters Roll Over at:
No Counters Reported
Sends Multi-Fragment Responses:
Yes
IMPLEMENTATION TABLE
OBJECT
REQUEST
RESPONSE
Object
Number
Variation
Number
Description
Function Codes
(decimal)
Function Codes
(decimal)
Qualifier Codes
(hex)
1
1
Binary Input
1 (read)
129 (response)
00, 01 (start-
stop)
