When PCM frame is set to Off, many of the following transmitter parameters are
insignificant.
CRC4CRC4
Use the CRC4CRC4 radio buttons to enable (OnOn) or disable (OffOff) CRC4 in the
transmitted signal contained in the PCM Frame.
If you are uncertain whether the CRC4 should be selected or not, it is recommended to
enable the CRC4.
If Drop and InsertDrop and Insert of the total contents of a receiver is selected and the signal contains
CRC4, it is possible to either Bypass or Insert Sa-Bits.
Sa-BitsSa-Bits
When Drop and insertDrop and insert is set to OnOn, you can select Sa-bits of the frame.
Insert Sa-BitsInsert Sa-Bits: inserts 16 bits set in the field below into Sa-bits.
Bypass Sa-BitsBypass Sa-Bits: sends Sa-bits of the received frame as they are.
You can set the Sa-Bits value of the non-FAS words in the transmitted signal
when containing PCM Frame/CRC4. Touch the Sa-BitsSa-Bits setup field to open the
setup dialog box.
In the Sa-BitsSa-Bits dialog box, change the individual Sa-bits by touching on the
relevant bit keys - this will toggle the bit key's binary value from logic 1 to 0 or
vice versa. Touch OkOk to accept the changes and close the dialog.
Contents tabContents tab
The ContentsContents tab contains the following parameters:
