RAIRAI: Remote Alarm Indication
IDLEIDLE: Idle Signal
LSSLSS: Link Status Signal
Errors
BPV ErrorBPV Error: Bipolar Violation error
Pattern errorPattern error: Pattern error
Pattern slipsPattern slips: Pattern slips
Parity errorParity error: Parity error
F-bit errorF-bit error: F-bit error
C-bit errorC-bit error: C-bit error
FEBEFEBE: Far End Block Error
55..66..33..44 AlignmentAlignment
Touching the AlignmentAlignment button in the status area of the Ports SetupPorts Setup screen
displays the status shown below.
Alignment status when the frame type is M13Alignment status when the frame type is M13
Alignment status when the frame type is C-bitAlignment status when the frame type is C-bit
