2. Touch JoinJoin to send a Join message from the Network Master to the MLD host.
The button name changes to LeaveLeave.
In this state, the Network Master receives packets whose source address
matches the group address. The Src IPSrc IP address in the Stream Setup screen is
not used in receiving packets.
Also, the IP address display is followed by (multicast hostmulticast host).
3. Touch LeaveLeave to send a Leave message to the MLD host.
Touching SetupSetup for MLD Host will open the MLD host setupMLD host setup dialog box.
Touch the Group addressGroup address box to set the multicast address of the group. (All the
first eight bits are "1".)
Select a version from the MLD versionMLD version list. The supported functions vary
depending on the protocol version.
OptionOption
FunctionFunction
JoinJoin LeaveLeave
GeneralGeneral
QueryQuery
Group specificGroup specific
query responsequery response
SourceSource
filterfilter
MLDv1MLDv1 ✓ ✓ ✓ ✓ -
MLDv2MLDv2 ✓ ✓ ✓ ✓ *
✓: Supported, -: Not supported,
*: The Network Master does not support the function.
MLDv2 Source filterMLDv2 Source filter
Selecting the Source enableSource enable check box enables the Source Filter function. Set
the IP address for the MLD frame source.
