SourceSource
Allows you to specify the time reference that the Network Master uses to send
PTP messages.
InternalInternal: Current instrument time
GPSGPS: GPS time (Requires external GPS receiver)
Priority #1/#2Priority #1/#2
Allows you to specify the priority 1 and priority 2 values. Acceptable values are
between 0 and 255.
ClassClass
Allows you to specify the clock class. Acceptable values are between 0 and
255.
IdentityIdentity
Allows you to specify the 64 bit clock identity. You can either use the Source
MAC to generate the identity (by selecting the Use src MACUse src MAC check box) or you
can type the identity yourself (using the address field).
Time sourceTime source
Either choose one of the predefined time sources in the drop-down menu, or
select User definedUser defined and enter a value manually. Acceptable values are between
0x00 and 0xFF.
AccuracyAccuracy
Either choose one of the predefined accuracy in the drop-down menu, or select
User definedUser defined and enter a value manually. Acceptable values are between 0x00
and 0xFF.
ePRTC connectedePRTC connected, PRTC connectedPRTC connected, and PRTC not connectedPRTC not connected are available
when:
Profile is set to G.8275.1G.8275.1, G.8275.2G.8275.2 or User DefinedUser Defined and Slave modeSlave mode is cleared.
PRTC: Primary Reference Time Clock
flagFieldflagField
