(DEIDEI) and a Priority Code Point (PCPPCP).
Displays a Tag Protocol Identifier (TPIDTPID).
I-TagI-Tag: Allows you to set a VLAN Identifier (VIDVID), a Drop Eligible Indicator
(DEIDEI), a Priority Code Point (PCPPCP) and a User Customer Address (UCAUCA).
Displays a Tag Protocol Identifier (TPIDTPID).
Dst MACDst MAC: Touch the field to enter the PBB destination address.
Src MACSrc MAC: Touch the field to enter the PBB source address.
EthertypeEthertype: When the VLAN layer is added, select the type from
0x81000x8100, 0x88A80x88A8, 0x91000x9100 or 0x92000x9200.
MPLS, MPLS-TP layerMPLS, MPLS-TP layer
Select the number of levels using Level countLevel count drop down menu.
Level countLevel count Up to eight levels of MPLS fields can be inserted in the frame. The
number of MPLS fields is selected through the Level countLevel count drop-down menu,
and each level is set up individually.
LabelLabel Allows you to set up a denoting of the MPLS.
Traffic ClassTraffic Class Allows you to set up the 3 bit value EXP (Experimental - used in
MPLS to support differentiated services (priority)).
TTLTTL Allows you to set up the 8 bit value TTL (Time To Live).
VLAN layerVLAN layer
When the VLAN level count is 2, the two VLAN levels will be designated S-
VLAN and C-VLAN. S-VLAN is short for Service provider VLAN and C-VLAN is
short for Customer VLAN.
Level countLevel count Up to eight levels of VLAN can be inserted in the frame. The
number of VLAN fields is selected through the Level countLevel count drop-down menu,
and each level is set up individually.
IDID Touching the IDID (VLAN ID) button launches a setup dialog box from which it
is possible to set up a denoting of the virtual LAN.
DEIDEI Selecting the DEIDEI check box sets a 1-bit flag denoting whether MAC
addresses inside the frame are in canonical format.
PriorityPriority It is possible to set up the priority level of each frame.
EthertypeEthertype When the Level count is more than one, select the type from
0x81000x8100, 0x88A80x88A8, 0x91000x9100 or 0x92000x9200.
The higher layer protocol number is displayed in the lowest line.
