Allows you to specify the Local Maintenance Point ID, which will identify the
unit in the MA (Maintenance Association).
MEP: Maintenance End Point
DomainDomain
Allows you to identify the network or part of the network for which faults in
connectivity are managed.
MD LevelMD Level
Use the drop-down menu to specify the MD (Maintenance Domain) level at
which the MEP exists.
AssociationAssociation
Allows you to specify the Main Association Identifier.
CCM tabCCM tab
The CCMCCM tab contains the Continuity Check Message parameter:
CCM intervalCCM interval
Use the drop-down menu to specify the frequency at which CCMs are
transmitted and expected to be received.
LBM tabLBM tab
The LBMLBM tab contains the Loopback Message parameters:
Optional TLVOptional TLV
Use the drop-down menu to select a TLV type (Type, Length and Value), if
relevant. The possible types are: Data TLVData TLV and Test TLVTest TLV. If you select one of
the TLV types, fields for specifying the LengthLength and ValueValue will appear.
LengthLength
Only available if a Data or Test TLV type has been selected. Allows you to
specify the length of the TLV.
ValueValue
Only available if a Data TLVData TLV or Test TLVTest TLV type has been selected. Allows you to
specify the value of the TLV. Note that for the Data TLV type, this field is an
entry field where you open an editor and type the value; for the Test TLV type,
it is a drop-down menu.
LTM tabLTM tab
The LTMLTM tab contains the Link Trace Message parameters:
TTLTTL
Allows you to specify a TTL (Time to Live) value. Used to indicate whether or
not an LTM should be terminated by the receiver.
Trans IDTrans ID
Allows you to specify the transaction number for the LTM.
