LinkLink
Link partner abilitiesLink partner abilities
Timestamp sourceTimestamp source
availabilitiesavailabilities
LOSLOS
Indicates whether LOS (Loss of Signal) of the transceiver is occurred or not.
LinkLink
Indicates whether Ethernet link is established or not.
Auto negotiation completeAuto negotiation complete
Indicates whether Auto negotiation is completed or not.
SpeedSpeed
10 Mbps, 100 Mbps, 1 Gbps, 10 Gbps, 25 Gbps, 40 Gbps, 100 Gbps, 200 Gbps,
or 400 Gbps is shown.
DuplexDuplex
FDX: Full Duplex, HDX: Half Duplex.
MDI/MDIXMDI/MDIX
When ElectricalElectrical interface type is selected, interface type is displayed.
MDI: Medium Dependent Interface, MDIX: Medium Dependent Interface
Crossover
Local clockLocal clock
When IEEE 1588.v2 is turned on, Master or Slave is shown.
When ElectricalElectrical interface type is selected, the Link partner abilities is shown.
Pause capablePause capable
Indicates in green when the device is capable of flow control using Pause
request.
Asym. pause requestAsym. pause request
Indicates in green when the device is capable of asymmetric flow control using
Pause request.
Remote faultRemote fault
Indicates in red when the device is sending the remote fault signal.
Speed/DuplexSpeed/Duplex
Available speed and duplex are indicated in green.
The status indicators for the external signal used as time stamp are displayed.
This area is available and indicators turn green or red if both of the following
conditions are met. The status that becomes available varies depending on the
setting for SourceSource in Stream - Meas screen. The status of the external signals
used for timestamp is shown.
In the Stream Measurement area of the Stream tab, one of JitterJitter, LatencyLatency, and
Service disruptionService disruption is selected.
In the Stream Measurement area of the Stream tab, other than InternalInternal is
selected.
Ext. ref. 10MHzExt. ref. 10MHz
Green: The external 10 MHz clock is available.
