802.1ag status802.1ag status
informationinformation
Message buttonsMessage buttons
Allows you to send messages either to a remote MEP ID or to a unicast MAC
Address.
U-LBMU-LBM: Data-path integrity to/from the far-end to/from one address (unicast).
M-LBMM-LBM: Data-path integrity to/from the far-end to/from multiple addresses
(multicast).
LTMLTM: Enumerate and identify all hops between two end points.
Fault buttonFault button
The fault messages are sent when the button is active.
CCMCCM: Continuity Check Messages.
Devices tabDevices tab
Shows the current status of the devices.
The outer circle of the colored Lamp in the Status column represents the CCM
status (green means that CCMs are received from that RMP, red means no
CCMs are received). The inner circle indicates whether the RDI bit in the CCM
frame is set (red) or not set (green).
Decode tabDecode tab
Shows extra information about LTM frames.
