This screen presents the results from the Throughput and frame loss test.
The most important columns of the tables are the varied main parameters
Frame sizeFrame size and ThroughputThroughput and the performance parameters Frames lostFrames lost and
Loss rateLoss rate.
The order of the tables will vary depending on the test mode and the relation of the ports.
Refer to the table in "Throughput" subsection of Test Results.
66..99..33..55 Latency/JitterLatency/Jitter
Touching the Latency/JitterLatency/Jitter button in the navigation area will display the
screen shown below.
This screen presents the results from the Latency test.
The most important columns of the tables are :
the varied main parameters Frame sizeFrame size and ThroughputThroughput
the performance parameters MinMin, AvgAvg and MaxMax latency stated in micro
seconds
the performance parameters MinMin, AvgAvg and MaxMax jitter stated in micro seconds
