This screen presents results by each TCP connection of RTT, Throughput and
TCP Efficiency. Use the GraphGraph and TableTable buttons to switch between the tabular
form and a graphical presentation of the results.
Touching the button in navigation area switches the Test direction of results.
The results in Connection are:
ConnectionConnection: Connection number of the stream
Min RTTMin RTT: Minimum Round Trip Time
Avg RTTAvg RTT: Average Round Trip Time
Max RTTMax RTT: Maximum Round Trip Time
Tx THPTTx THPT: Transmitter throughput
TCP EfficiencyTCP Efficiency: The ratio of actual throughput against ideal throughput
The results in Total are:
Min RTTMin RTT: Minimum RTT in all connections
Avg RTTAvg RTT: Average Round Trip Time
Max RTTMax RTT: Maximum RTT in all connections
Tx THPTTx THPT: Sum of throughput in each connections
TCP EfficiencyTCP Efficiency: The ratio of total actual throughput of connections against
total ideal throughput of connections
66..1010..33..66 Event LogEvent Log
Touching the Event LogEvent Log button in the navigation area displays the screen
providing the event log data. Refer to Event Log of SDH/SONET/PDH/DSn
BERT application.
66..1010..33..77 StatisticsStatistics
Touching the StatisticsStatistics button in the navigation area displays the screen
providing the statistics data.
Refer to Statistics of BERT for the operation.
PerformancePerformance and FrameFrame are displayed as RFC 6349 Statistic result.
