Available Module Combinations Without MT1040A-020Available Module Combinations Without MT1040A-020
One module configurationOne module configuration
Trans. Type 1 OTDR
MT1040A MT1040A
Two modules configurationTwo modules configuration
Trans. Type 1 Trans. Type 1
Transport
Type 2
OTDR
OTDR GPS GPS
MT1040A MT1040A MT1040A MT1040A
Three modules configurationThree modules configuration
Trans. Type 1 OTDR GPS
OTDR
Transport
Type 2
Transport
Type 2
GPS
MT1040A MT1040A MT1040A
Three modules configuration (Four modules size)Three modules configuration (Four modules size)
OTDR
GPS
Transport
Type 2
MT1040A
When the module except for MU100010A and MU100011A is mounted on
back, equip with rear panel. B0771A Rear Panel Kit for MT1040A come with
different length screws.
When the MT1040A-020 Activate for 400G Dual/100G Quad Option is
installed and the G0419A AC Adapter is connected, two transport modules can
be attached to the Network Master in addition to Available Module
Combinations Without MT1040A-020.
When two transport modules are attached, the Network Master cannot work on battery
power.
With two transport modules attached, the battery doesn't charge when the Network
Master is powered on.
